Description
Features:
- Designed to link with a data modem as a direct-connect amplifier.
- Improves overall cellular connectivity in weak signal environments.
- Configurable to almost any Internet of Things (IoT) installation.
- Pre-approved by all major cell carriers under FCC “part 20” rules.
- Power over Coax: Amplifier and antenna can be positioned for maximum performance.
- Passive RF bypass failover keeps modem going if power is lost.
- Auto-power control to help ensure maximum signal output.
About:
The WilsonPro IoT 3.0 is a “Direct-Connect” solution for cellular network capable equipment and IoT devices. Compatible with all U.S. carrier networks, the IoT 3.0 connects directly with cellular modems and provides strong, reliable cell signal to guarantee successful IoT data transfer.
The IoT 3.0 is a single kit that offers different installation options:
- The 12V AC/DC power supply is ideal for ATMs, vending machines, or movie-rental kiosks with access to AC power outlets.
- The 12V hardwire kit with DC power supplied by a vehicle is ideal to amplify cell signals for an LTE-modem hotspot.
- The included MCX/MMCX cables are provided to interface with cellular-based home or business security systems if necessary.
The IoT 3.0 compact form factor is ideal for custom-designed IoT communication systems built within tightly constrained spaces. FCC certified, the IoT 3.0 allows OEMs to source a compact, powerful, and highly compatible cell signal amplifier that comes ready to deploy. In locations where cellular connectivity is adversely affected by distance to cell towers, terrain obstructions, or building materials (like concrete and steel), the IoT 3.0 is a proven go-to solution.
Specifications:
| MODEL NUMBER | 460079 |
| FREQUENCIES | Band 12 700 MHz |
| Band 13 700 MHz | |
| Band 5 850 MHz | |
| Band 4 1700/2100 MHz | |
| Band 25/2 1900 MHz | |
| MAX GAIN | 15 dB |
| MAX UPLINK POWER | 24 dBm |
| MAX DOWNLINK POWER | -5 dBm |
| IMPEDANCE | 50 Ohm |
| POWER | 12V DC / 2A |
| CONNECTORS | N-Female |
| AMPLIFIER DIMENSIONS | 5.4 x 4.2 x 1.4 in |
| AMPLIFIER WEIGHT | 1.58 lbs |
